353Y/JLT Easy Mounting Bracket OEM Peristaltic Pumps

Models: 353Yx/JLT
Maximum channel quantity: 2
Reference flow rate: ≤8300ml/min

■ Easy-to-install peristaltic pump head, easy to disassemble and install tubes;
■ The pump head can be installed with 73# and 82# tubes, and the flow rate of a single pump can reach 8300ml/min;
■ Driven by AC motor, the motor is available in fixed speed type and speed regulating type;
■ The pump head is available in single pump head and double pump head configurations.

Product Description
Product Video
Related Downloads

353Y/JLT Easy Mounting Bracket OEM peristaltic pump features a simple design, making installation and removal of tubing quick and convenient, greatly improving maintenance and operational efficiency. The pump head can support 73# and 82# tubing, with a maximum flow rate of up to 8300 ml/min, which meets the needs for high-flow applications. This peristaltic pump is powered by an AC motor, available in both fixed-speed and variable-speed options, giving users the flexibility to meet different application needs. Additionally, the pump head can be equipped with either a single or double pump head, providing a versatile range of fluid transfer requirements.

Product Configuration

Product Parameters

Product Parameters
Product Name	Bracket Peristaltic Pumps
Product Model	353Y/JLT
Voltage	AC 220V 50Hz/380V 50Hz
Power	≤120W
Work Environment	Temperature 0 (no icing)～60℃, relative humidity≤85%
Weight	8.85KG（with single pump head）
Outlet Pressure	≤0.27MPa
Noise	≤63dB (Testing environment noise≤40dB. The horizontal distance between the test product and the noise meter is 1 meter.)
Function	Start/stop, cw/ccw rotation, up/down speed

Reference Flow Rate

Reference Flow of Pump Head (unit: ml/min)
Motor Speed/Tube Type	Silicone tube
	73#(ID9.6*OD16.2)	82#(ID12.7*OD19.3)
150～415rpm	1800～5000	3000～8300
Pump Head qty	≤2	≤2
Flow Description	1. The flow rate is measured at room temperature of 23°C and no pressure at the inlet and outlet, while transporting clean water. 2. The total flow of pump heads ≈ single pump head flow * number of pump heads
